High Speed / Rapid Roll Doors

Control Access to your premises without interruption to your day-to-day operations with a KC Rapid Roll / Speed Door. These doors are manufactured with the need for efficiency, speed and reliability in mind: At Kirk Craig Ltd. we understand the importance of these characteristics when operating in a busy work yard that sees constant traffic.  KC Rapid Roll / Speed Doors are designed to open and close quickly, with the use of a number of simple triggers. All without slowing traffic or affecting access. The fast action of these doors allow for faster material handling, maintain desired temperatures, reduce heat loss, restrict sound flow, safe energy and reduce the chance of impact damage. Whether they are installed for light of heavy usage in harsh industrial environments, factories, warehouses distribution or cold storage facilities.
With two styles available to tailor to your site-specific requirements: Customisations can be made to the size, material, finish, choice of switch gear / trigger method and more.
A KC Rapid Roll / High Speed Door is the ideal solution where efficiency, speed and reliability are imperative. With a variety of finishes, and option for an image to be printed onto the face of the door to fit in with your site's aesthetics.
All backed up by our true, 24hr, 365 day a year emergency call out service, planned maintenance packages and repairs.

Useful Applications

Our KC Rapid Roll / High Speed Doors are often used for both internal and external applications, including but not limited to:

  • Warehouses
  • Factories
  • Loading Bays
  • Transport Yards
  • Sites where climate control is required; e.g. food processing, chemical and pharmaceutical industries.
Get a free quote
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button
  • Slide title

    Write your caption here
    Button

KC Self-Repair Rapid Roll

The innovative design of the curtain edge firmly holds the curtain into the side guides, and if impacted, the curtain will release from the side guid and automatically re-set on the next door cycle. Please contact our office to discuss full specification and requirements

Features & Benefits

  • Self Repairing
  • Motor with inverter controls to allow operating speeds up to 2.5m/s
  • Oil-free guides to allow doors to withstand wind-loads up to 120km/h
  • Quiet Operation
  • Soft-touch bottom edge / bottom rail
  • 22 ray light curtain
  • Hand crank for emergency manual opening
Speed: Maximum Opening Speed: 2.5m/s.  -   Maximum Closing Speed: 0.8m/s
Maximum Sizes: Maximum Width: 8m. x  Maximum Height: 8m
Wind Class
  • 3m x 3m: Class 3
  • 4m x 4m: Class 2
  • 5m x 5m: Class 2
Operating Temperature: -30 degrees C - +70 degrees C (Heating kits available as an optional extra)
Safety Barrier
  • 22 Ray light curtain
  • Heating Sensor for wet environments
Timed Close: 0 - 200 seconds: Selected on installation
Vision Panels: 2 rows
Photocell: Transmitter / Receiver

Additional Curtain Options

  • Various RAL colour options
  • Logos / images and digital print can be applied to the curtain
  • "T" cut emergency exit in the curtain
  • Insulated curtain

Control Options

  • Inverter controls in a steel case
  • Remote / Radio control
  • Pull switch with optional gallows
  • Key Switch
  • Digital keypad
  • Key fob
  • Rocker switch
  • Timer closing
  • Motion detectors
  • Magnetic induction loops

Additional Safety Options

  • UPS Battery Back Up
  • Proximity Sensors
  • LED Traffic Lights
  • Flashing Warning Lights
Get a free quote

KC Reinforced Rapid Roll

A simple self-supporting modular design, intended for continual use: The curtain has horizontal bars fitted into pockets welded to the curtain, this give up to a Class 4 wind-load making the KC Reinforced Rapid Roll ideal for exposed locations. Please contact our office to discuss full specifications and requirements

Features & Benefits

  • Up to 1m/s opening speed
  • 3ph control panels
  • Wireless safety edge
  • Ideal for large and exposed openings
  • Manual release handle
  • Self-supporting modular design
  • Helps to reduce heat loss
Speed: Maximum Opening Speed: 1m/s. -  Maximum Closing Speed: 0.8m/s
Maximum Sizes: Maximum Width: 20m x Maximum Height: 10m
Wind Class
  • 3m x 3m: Class 4
  • 5m x 5m: Class 3
  • 8m x 8m: Class 2
  • Above 8m: Class 1
Operating Temperature:  -30 degrees C to +70 degrees C (Heating kits available as an optional extra)
Safety Edge: Wireless
Photocell: Transmitter / Receiver
Timed Close: 0 - 200 seconds: Selected on installation
Vision Panels: 2 rows

Additional Curtain Options

  • Various RAL colour options
  • Logos / images and digital print can be applied to the curtain
  • Insulated curtain

Control Options

  • Remote / Radio control
  • Pull switch with optional gallows
  • Key switch
  • Digital keypad
  • Motion detectors
  • Magnetic induction loops

Additional Safety Options

  • Proximity sensors
  • LED Traffic lights
  • Flashing warning lights
  • Safety light grid
  • Radar sensors
